12V 24Ah LiFePo4 Battery
It is a complete solution for lithium replacement of lead-acid batteries. It can be used in RVs, electric vehicles, electric boats, home energy storage, base station backup power, UPS and solar/wind energy storage systems.
12.8V 24Ah Battery Specs
-
Work Voltage Range 10.8~14.6V
-
Nominal Voltage 12.8V
-
Nominal Capacity 24Ah
-
Rated Energy 307.2Wh
-
Max Discharge Power 384W
-
Standard Charge Current 5A
-
Recommend Charge Current ≤15A
-
Max Charge Current 24A
-
Recommend Discharge Current ≤25A
-
Max Continue Discharge Current 30A
-
Peak Discharge Current (10S) 60A
-
Resistance ≤30mΩ
-
Lifespan (25℃,0.5C,80%DOD) >6000
-
Waterproof IP65
-
Weight 3Kg
-
Size (Length * Width * Thick) 165*126*175mm
Hongyitai Batery Charging Curve
12.8V 24Ah lithium battery charging curve
On the left is the charging curve of a 12.8V 24Ah battery at different rate discharge curve @25℃
Main applicates for Hongyitai 12.8V 24Ah lifepo4 battery
Outdoor and camping equipment:
For camping and outdoor activity equipment such as pull-out refrigerators, outdoor LED lights, outdoor network head units, and more.
Ship and Marine Equipment:
For marine electronic equipment such as ship power systems, fishfinders, ship interior electronics, and other marine electronic equipment.
Solar Energy System:
Can be used for off-grid solar systems and home solar energy storage systems.
Low-speed vehicles:
Applicable to electric scooters, electric wheelchairs, golf carts and other small electric vehicles.
About 12.8V 24Ah deep cycle battery
12.8V 24Ah LiFePo4 battery features
- Long cycle life
- High energy density
- High discharge power
- Fast charging
- Wide temperature operating range
- Low self-discharge
- Built-in BMS protection
- Supports series and parallel connection
- Maintenance-free use
Lithium-ion battery production process
#1 Cell Selection
Select the number of 18650 cells or LiFePO4 cells we need. Ensure they works fine.
#2 Battery Sorting
Make sure that the capacity, voltage, and internal resistance of the selected cells are consistent.
#3 Arrangement & Assembly
Combine the required battery modules in a series-parallel manner.
#4 Spot Welding
The positive and negative terminals of the battery are connected via nickel tabs to form the desired capacity or voltage.
#5 Mounting Protection Board
Connect the protection board on the battery pack to ensure that its overcharge, overdischarge and short circuit protection functions properly.
#6 Packaging & Aging
Wrap the battery pack in a PVC or metal casing while charging and discharging to activate the battery pack performance.
