24 volt forklift battery
The 24V forklift battery is an industrial battery mainly used for small electric lifting equipment. There are two types of batteries: lead-acid batteries and lithium iron phosphate (LiFePO4) batteries. These batteries are crucial for powering various types of forklifts and other material handling equipment.
We primarily produce 24V lithium-ion forklift batteries with capacities of 50Ah, 100Ah, and 200Ah.
If you have other requirements for 24V lithium-ion batteries, please contact us.
24V 100Ah Battery Specs
-
Work Voltage Range 22~29.2V
-
Nominal Voltage 25.6V
-
Nominal Capacity 100Ah
-
Rated Energy 2560h
-
Max Discharge Power 2560W
-
Standard Charge Current 20A
-
Recommend Charge Current ≤50A
-
Max Charge Current 100A
-
Recommend Discharge Current ≤100
-
Max Continue Discharge Current 100A
-
Peak Discharge Current (10S) 200A
-
Resistance ≤10mΩ
-
Lifespan (25℃,0.5C,80%DOD) >6000
-
Waterproof IP65
-
Weight 12Kg
-
Size (Length * Width * Thick) 328*172*215mm
Main applicates for Hongyitai 25.6V 100Ah lifepo4 battery
The 24v lifepo4 battery is a complete solution for lithium replacement of lead-acid batteries. It can be used in RV, electric car, electric boat, home energy storage, base station backup power, UPS and solar/wind energy storage systems, forklift.
24V 100Ah deep cycle battery factory
How to select 24v forklift battery charger
Key Factors for Choosing a 24V Forklift Battery Charger
Battery Compatibility
- Battery Type: Identify the type of your forklift battery (e.g., lead-acid battery, lithium-ion battery, etc.) and choose a compatible charger. Different types of batteries require different charging stages and protection measures.
- Battery Capacity (Ah): Ensure the charger’s amp-hour (Ah) output matches the battery’s capacity. It is generally recommended that the charger’s output current should be 20% to 30% of the battery capacity, so consider a charger with a current output of 20~30A.
- Battery Type: Identify the type of your forklift battery (e.g., lead-acid battery, lithium-ion battery, etc.) and choose a compatible charger. Different types of batteries require different charging stages and protection measures.
Charging Capacity and Voltage Requirements
- Voltage: Ensure the charger’s output voltage is between 24.8V and 25.2V to match your forklift battery.
- Charging Current: Select an appropriate charging current (amps). For example, for a 100Ah battery, a suitable charging current range is around 20A.
- Voltage: Ensure the charger’s output voltage is between 24.8V and 25.2V to match your forklift battery.
Charging Time and Efficiency
- Charging Time: Consider the charger’s charging speed. Fast chargers can fully charge the battery in a shorter time but may reduce the battery’s cycle life.
- Efficiency: High-efficiency chargers can reduce energy loss, improve charging speed, and extend battery life.
- Charging Time: Consider the charger’s charging speed. Fast chargers can fully charge the battery in a shorter time but may reduce the battery’s cycle life.
Safety Features
- Overvoltage, Overcurrent, Overheat Protection: Choose a charger with these protection features to prevent battery damage due to excessive voltage, current, or temperature.
- Reverse Polarity Protection: Prevents damage due to incorrect wiring.
- Automatic Shut-off: Charger automatically disconnects when the battery is fully charged.
- Overvoltage, Overcurrent, Overheat Protection: Choose a charger with these protection features to prevent battery damage due to excessive voltage, current, or temperature.
Portability and Ease of Use
- Portable Design: If frequent movement of the charger is required, choose a lightweight and easy-to-carry model.
- Display and Indicators: Choose a charger with an LCD display or indicator lights for easy real-time monitoring of the charging status.
- Portable Design: If frequent movement of the charger is required, choose a lightweight and easy-to-carry model.
