24V LiFePo4 Battery
Lightweight
It weighs only 1/3 of the weight of a lead-acid battery. It makes installation and movement easier.
Multiple Applications
Compatible with RV/campers caravans, ships, golf carts, solar off grid system.
High Effective Protection
Prevent its overcharge, over-discharge, over-current, short-circuit, self balance.
Long Life Cycle
It allows cycles 6000+, 4 times compared with lead acid batteries.
24V 50Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 50Ah
Rated energy: 1280Wh
Recommend charge current: ≤25A
Peak discharge current: 100A
Internal resistance: ≤20mΩ
24V 100Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 100Ah
Rated energy: 2560Wh
Recommend charge current: ≤50A
Peak discharge current: 200A
Internal resistance: ≤15mΩ
24V 150Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 150Ah
Rated energy: 3840Wh
Recommend charge current: ≤50A
Peak discharge current: 200A
Internal resistance: ≤15mΩ
24V 200Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 200Ah
Rated energy: 5120Wh
Recommend charge current: ≤80A
Peak discharge current: 200A
Internal resistance: ≤15mΩ
24V 10Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 10Ah
Rated energy: 256Wh
Recommend charge current: ≤2A
Peak discharge current: 40A
Internal resistance: ≤70mΩ
24V 12Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 12Ah
Rated energy: 307.2Wh
Recommend charge current: ≤6A
Peak discharge current: 36A
Internal resistance: ≤50mΩ
24V 20Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 20Ah
Rated energy: 512Wh
Recommend charge current: ≤10A
Peak discharge current: 60A
Internal resistance: ≤60mΩ
24V 300Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 300Ah
Rated energy: 7680Wh
Recommend charge current: ≤60A
Peak discharge current: 300A
Internal resistance: ≤10mΩ
24V 30Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 30Ah
Rated energy: 768Wh
Recommend charge current: ≤15A
Peak discharge current: 60A
Internal resistance: ≤45mΩ
24V 60Ah LiFePo4 Battery
Nominal voltage: 25.6V
Nominal capacity: 60Ah
Rated energy: 1536Wh
Recommend charge current: ≤12A
Peak discharge current: 120A
Internal resistance: ≤30mΩ
Elevate your trolling motor performance
24V Lifepo4 batteries are designed specifically for 50-150 pound thrust motors. Provide stable and reliable electricity, improve performance, and extend operating time.
How to select 24v lifepo4 battery charger
When choosing to charge a 24V lithium iron phosphate battery, the following 3 points need to be considered.
1. Voltage compatibility
Charging voltage: The recommended charging voltage is approximately 28.8V to 29.2V.
2. Charging current
Rated current: It is recommended to use a charger with a rated ampere hour of 10-30%. For example, for a 25.6V 100Ah battery pack, it is best to use a charger with a current of 10-30A.
3. Safety features
It has overcharge, overdischarge, overheating, and short circuit protection. After being fully charged, it is best to have an automatic cut-off switch mechanism.
- 29.2V Lithium Battery Charger
- CE-EMC
- Eco Friendly
24v lifepo4 battery voltage chart
On the left are voltage states under different conditions, which help you better understand and use the Hongyitai 24V lifepo4 lithium battery.
- Charging characteristics @0.5C 25℃
- Different DOD discharge cycle life curve @1C
- Different rate discharge curve @25℃
- Different temperature discharge curve @0.5C
- Different temperature self discharge curve
- State of charge curve @0.5C 25℃
24v lead acid replacement by lithium
The main product list for 25.6V lifepo4 battery replacement lead acid is listed below. It includes voltage, capacity, dimensions, cycle life, weight and protection board information.
Model | Voltage (V) | Capacity (Ah) | Dimension (Leng*Width*Height) (mm) | Lifespan (25℃,0.5C,80%DOD) | Weight (Kg) | Protection Function | Know More |
|---|---|---|---|---|---|---|---|
HYT244 | 25.6 | 4 | 190*74*68 | >6000 | 1 | Yes | |
HYT2450 | 25.6 | 50 | 328*172*215 | >6000 | 12 | Yes | |
HYT24100 | 25.6 | 100 | 522*240*218 | >6000 | 23 | Yes | |
HYT24150 | 25.6 | 150 | 522*240*218 | >6000 | 32 | Yes | |
HYT24200 | 25.6 | 200 | 522*240*218 | >6000 | 42 | Yes |
Best 24v lifepo4 battery factory
- Minimum Order Quantity: 100 pieces per model.
- All orders come with the necessary certificates.
- Allows to custom to 10Ah, 20Ah, 30Ah, 50Ah, 60Ah, 100Ah, 200Ah capacitites.
Custom 24V Li ion Battery Procedure
- Information gathering: Evaluate the requirements from voltage, capacity, size, charge/discharge current multiplier, usage environment, working temperature and so on.
- Battery evaluation: 25.6V LiFePo4 batteries are made grade A lithium battery cells. It equips with comprehensive safety with advanced BMS.
- Production: From cell separation and pairing, cell fixing and reinforcing, adding plates and wires, insulation protection, to built-in to the fixed shell.
- Testing and shipping: We do at least 1~2 charging and discharging cycles to activate the battery performance. Verify and monitor each cell voltage, internal resistance and other information.
Why select Hongyitai as 24V lifepo4 battery supplier
- Grade-A cells at a good price
We do 100% testing of all Hongyitai batteries before shipping to you, with grade-A cells and high-quality materials at reasonal prices.
- 7~15 working days fast delivery
In order to let you start your quality life faster, we are able to deliver them soon. - 5 years warranty
Hongyitai provides a 5-year warranty for batteries and free consultation support. Let ‘s make it easy and enjoyable to use our batteries.
FAQs for 25.6V lifepo4 batteries
25.6V LiFePo4 batteries typically consist of 8 lifepo4 battery cell connected in series. Each LFP battery cell has a nominal voltage of 3.2V. As battery series boosts its voltage, the final voltage of 3.2 * 8=25.6V.
Fully charged voltage: 3.65*8=29.2V
Nominal voltage: 3.2*8=25.6V
Discharge cutoff voltage: 2.5*8=20.0V
There are mainly 2 stages for charging 25.6V LiFePo4 battery:
Constant current and constant voltage stage: 29.2V 0.5C or 0.2C constant current and constant voltage charging until the voltage reaches 29.2V.
Constant voltage stage: continue to charge at 29.2V, with the current getting smaller and smaller, until the end of 0.02C current.
